15055 - 15056 - 15057 -2823
I Left
D Right
D Articles manufactured upon order
15055 - 15056 - 15057 - 15058 C2A
I Left
D Right
D Articles manufactured upon order
15083
D Articles manufactured upon order
Lemken Smarag
I Left
D Right
D Articles manufactured upon order
Ref. | C | A | B | C | Grs. | B | E | M | D |
15055-A 80 HRS | 12 | 80 | 243 | 1500 | 500 | 1199A | 1285A | ||
15055-B CP 80 HRS DURATOP | 15 | 80 | 250 | 2000 | 300 | 1199A | 1285A | ||
15055-B80-CP-2A-3P DURATOP | 20-40 | 80 | 275 | 57 | 4030 | 250 | 1199A | 1285A | |
15055-B80-PL-CP-4P DURATOP | 30 | 80 | 275 | 57 | 4300 | 250 | 1199A | 1285A | 100 |
15055-B 120 HRS | 12 | 120 | 2300 | 300 | 1199A | 1285A | 100 | ||
15056-A D HRS | 10 | 172,5 | 60 | 1700 | 300 | HEX | M12 | ||
15056-A I HRS | 10 | 172,5 | 60 | 1700 | 300 | HEX | M12 | ||
15056-A D CA1 HRS | 10 | 172,5 | 60/60 | 1700 | 300 | HEX | M12 | 100 | |
15056-A I CA1 HRS | 10 | 172,5 | 60/60 | 1700 | 300 | HEX | M12 | 100 | |
15056-B D HRS | 10 | 101 | 60 | 1250 | 400 | HEX | M12 | ||
15056-B I HRS | 10 | 101 | 60 | 1250 | 400 | HEX | M12 | ||
15056-B D CA1 HRS | 10 | 101 | 60/60 | 1250 | 400 | HEX | M12 | 100 | |
15056-B I CA1 HRS | 10 | 101 | 60/60 | 1250 | 400 | HEX | M12 | 100 | |
15057-A 80 D HRS | 8 | 80 | 410 | 57 | 1950 | 300 | 1199A | 1285A | |
15057-A 80 I HRS | 8 | 80 | 410 | 57 | 1950 | 300 | 1199A | 1285A | |
15057-B 100 D HRS | 8 | 100 | 410 | 57 | 2700 | 300 | 1199A | 1285A | 50 |
15057-B 100 I HRS | 8 | 100 | 410 | 57 | 2700 | 300 | 1199A | 1285A | 50 |
15058-A 80 D HRS | 8 | 80 | 260 | 57 | 1200 | 400 | 1199A | 1285A | 50 |
15058-A 80 D CA1 HRS | 8 | 80 | 260 | 1200 | 400 | 1199A | 1285A | 50 | |
15058-A 80 I HRS | 8 | 80 | 260 | 57 | 1200 | 400 | 1199A | 1285A | 50 |
15058-A 80 I CA1 HRS | 8 | 80 | 260 | 1200 | 400 | 1199A | 1285A | 50 |
D Right
D Articles manufactured upon order
15056-A: 370 mm working width 2 wings and tine
15056-B: 240 mm working width 2 wings and tine
HEX: DIN 931 hexagonal screw and DIN 934 nut, ref. 1199H1260A without Bellota markings
DURATOP: Point with tungsten carbide
Fits with 2823 tine.
15056 A/B CA1: with four holes.
15058 CA1: 1 mounting hole
Ref. | C | A | B | C | Grs. | B | E | M | D |
15055-C2A HRS | 12 | 80 | 250 | 57 | 1750 | 500 | 1199A | 1285A | |
15055-C2A-CP HRS DURATOP | 15 | 80 | 250 | 57 | 2130 | 300 | 1199A | 1285A | |
15057-C2A CENTRAL | 8 | 80 | 258 | 1230 | 200 | 1199A | M12 | 50 | |
15057-A 80 D C2A HRS | 8 | 80 | 380 | 1300 | 300 | 1199A | 1285A | 50 | |
15057-A 80 I C2A HRS | 8 | 80 | 380 | 1300 | 300 | 1199A | 1285A | 50 | |
15058-A 80 D C2A HRS | 8 | 80 | 235 | 800 | 400 | 1199A | 1285A | 50 | |
15058-A 80 I C2A HRS | 8 | 80 | 235 | 800 | 400 | 1199A | 1285A | 50 | |
15056 C D | 10 | 221 | 60 | 2450 | 200 | HEX | M12 | 100 | |
15056 C I | 10 | 221 | 60 | 2450 | 200 | HEX | M12 | 100 | |
15056 C D AP2 | 10 | 221 | 60 | 2600 | 200 | HEX | M12 | 100 | |
15056 C I AP2 | 10 | 221 | 60 | 2600 | 200 | HEX | M12 | 100 |
D Right
D Articles manufactured upon order
15056-C: 465 mm working width 2 wings and tine
DURATOP: Point with tungsten carbide
AP2 DURATOP: High resistance to wear Hardfacing material.
Fits with 2823 tine.
HEX: DIN 931 hexagonal screw and DIN 934 nut, ref. 1199H1260A without Bellota markings
15083-80X12
15083-80X14
15083-100X12
Ref. | O. Ref. | C | A | B | Grs. | B | E | M | D |
15083-80X12 | 506064 | 12 | 80 | 280 | 1900 | 400 | 1199A | M12 | 100 |
15083-80X14 | 506065 | 14 | 80 | 280 | 2200 | 300 | 199A | M12 | 100 |
15083-100X12 | 506014 | 12 | 100 | 280 | 2400 | 250 | 1199A | M12 | 100 |
Lemken Smarag
Ref. | O. Ref. | C | A | B | C | Grs. | B | E | M | D |
1595 10 CA | 4679105 | 10 | 150 | 194 | 40/70 | 2350 | 125 | 1199A | M12 | |
1597-A 8 CA | 3374395 | 8 | 100 | 295 | 1850 | 400 | 1199A | M12 | ||
1597-B 8 CA | 3374394 | 8 | 100 | 290 | 1850 | 250 | 1199A | M12 | ||
1598 8 D CA | 3374398 | 8 | 110 | 300 | 2400 | 300 | 1199A | M12 | 100 | |
1598 8 I CA | 3374399 | 8 | 110 | 300 | 2400 | 300 | 1199A | M12 | 100 | |
1515 10 CA | 3374388 | 10 | 120 | 235 | 1740 | 500 | 1199A | M12 | ||
1515 12 CA | 3374392 | 12 | 120 | 235 | 2050 | 500 | 1199A | M12 | ||
1515 12 CA AP2 DURATOP | 3374392 | 12 | 120 | 235 | 2250 | 450 | 1199A | M12 | 100 | |
1515 12 B CA | 3374386 | 12 | 80 | 235 | 1550 | 500 | 1199A | M12 | 100 | |
1596 10 D CA | 3374416 | 10 | 349 | 130 | 70 | 2100 | 450 | 1199G | M12 | |
1596 10 I CA | 3374417 | 10 | 349 | 130 | 70 | 2100 | 450 | 1199G | M12 | |
1516 10 D CA | 3374418 | 10 | 349 | 130 | 70 | 2035 | 400 | 1199G | M12 | |
1516 10 I CA | 3374419 | 10 | 349 | 130 | 70 | 2035 | 400 | 1199G | M12 | |
1516 11 D CA | 3374420 | 11 | 381 | 130 | 70 | 2635 | 370 | 1199G | M12 | |
1516 11 D CA AP2 DURATOP | 3374420 | 11 | 380 | 130 | 70 | 3000 | 300 | 1199G | M12 | |
1516 11 I CA | 3374421 | 11 | 381 | 130 | 70 | 2635 | 370 | 1199G | M12 | |
1516 11 I CA AP2 DURATOP | 3374421 | 11 | 380 | 130 | 70 | 3000 | 300 | 1199G | M12 | |
1516B 10 D CA | 3374428 | 10 | 249 | 130 | 70 | 1635 | 400 | 1199G | M12 | 100 |
1516B 10 I CA | 3374429 | 10 | 249 | 130 | 70 | 1635 | 400 | 1199G | M12 | 100 |
1517 CA | 3374356 | 5 | 256 | 174 | 780 | 300 | 1199A | M10 |
D Right
D Articles manufactured upon order
Fits with 2446 tine.
AP2 DURATOP: High resistance to wear Hardfacing material.
